Amphenol AHDP04-24-07SN-STA Rectangular Wire-To-Board Header Female Receptacle High Current IP68 IP69K Sealed Automotive Connector

  • Amphenol AHDP04-24-07SN-STA Rectangular Wire-To-Board Header Female Receptacle High Current IP68 IP69K Sealed Automotive Connector
Plaats van herkomst VS
Merknaam Amphenol
Certificering ROHS
Modelnummer AHDP04-24-07SN-STA
Min. bestelaantal 100
Prijs 10USD
Verpakking Details Tape & Reel (TR)
Levertijd 2 tot 3 weken
Betalingscondities T/T
Levering vermogen 10000
Productdetails
U kunt de producten die u nodig heeft aanvinken en met ons communiceren op het mededelingenbord.
Model
AHDP04-24-07SN-STA
AHDP04-24-07PN-STACL22
AHDP04-24-07PN-STA
Laat een bericht achter
Model
Productomschrijving

Amphenol AHDP04-24-07SN-STA Rectangular Wire-To-Board Header Female Receptacle High Current IP68 IP69K Sealed Automotive Connector



Description

The AHDP04-24-07SN-STA is an Amphenol automotive female receptacle rectangular wire-to-board header connector with IP68/IP69K high-grade ingress protection under mated status across full operating temperature range from -55°C to 125°C. It features stable electrical performance, superior waterproof & dustproof capability and consistent contact conductivity, which make it ideal for heavy-duty automotive wiring harness and PCB assembly applications. This 7-position connector adopts #12 specification contact diameter, rated for 80A at 40°C and 250V working voltage, compatible with wire gauge ranging from 2 to 10. The AHDP04-24-07SN-STA connector is available in standard bulk packaging.

Features

 7 Positions Automotive Female Receptacle Rectangular Wire-To-Board Header, #12 Contact Diameter
 IP68 / IP69K Heavy-Duty Ingress Protection When Mated
 Rated Current: 80A @40°C, Rated Voltage: 250V
 Wide Operating Temperature Range from -55°C to +125°C, applicable for wire gauge 2~10
 Totally Lead-Free; RoHS Compliant
 Standard Bulk Packing
 Totally Lead-Free & Fully RoHS Compliant
 Halogen and Antimony Free. “Green” Device





Applications

 Charger
 Voltage Adapter
 Switching Power Supply
 Graphic Card
 Precision Voltage Reference



Category Automotive / Rectangular Wire-To-Board Header Female Receptacle Connector
Mfr Amphenol
Product Status Active
Voltage - Output (Max) 250 V
Current - Output 80 A @40°C
Operating Temperature -55°C ~ +125°C
Mounting Type Board Mount
Package / Case Bulk Pack
Number of Positions 7 Positions
Gender Female
Contact Diameter #12
Mated IP Rating IP68 / IP69K
Compatible Wire Gauge 2 ~ 10
